Features
Wide range of AC input voltage 90-264VAC
Protections against: short circuit/over current/over voltage
Comprehensive protection, which can effectively prevent the impact from 2KV lightning and AC surge
Meet energy star level V (V2.0)
Common mode noise <2V (PK-PK)
Electrial Specifications
Input Voltage Range: 90 ～ 264VAC
Input Current:200mA
Output Voltage Range: ±5%
Average Efficiency: Meet energy star level V (V2.0)
MTBF: 50,000 hours at full load at 25℃ ambient, calculated per MIL-HDBK-217
Low Standby Power: 0.15W
Environmental Parameter
Operation Temp: 0℃ ～ 45℃
Storage Temp: - 20℃ ～ 60℃
Humidity : 5% to 95% non condenising
Saftey Approval
CCC（GB4943）
Dimensions
28.0mm (L) ; 27.8mm (W) ; 28.2mm (H)
Applications
ITE Equipment、Mobile Phone
Output data

Model	Voltage （V)	Current (A)	Ripple (mV)	115     230	Av. Eff.  (%)Min
UE05LD-050YYYSPAZ	5.0	0.1-1.0	200	Y     Y	68.17


YYY: 010-100 Stands for current  0.1-1.0A
