点击查看详细资料产品特性 | |||
医疗和ITE安全认证 | |||
2 MOPP 隔离保护 | |||
符合医疗设备达BF(∧)级别 | |||
接触电流 ≤ 50μA | |||
能效 DOE efficiency 六级 | |||
CoC V5 Tier 2(2016) | |||
待机功耗≤0.075W | |||
9V至36V输出, 最高36W | |||
工作海拨高度5000米 | |||
AC输入C8插座 | |||
涵盖短路保护、过压保护、过载保护; | |||
电气规格 | |||
输入电压:90~264VAC | |||
输入电流:0.5A | |||
待机功率:0.075W | |||
输出电压范围:±5% | |||
环境参数 | |||
工作温度: 0~40℃ | |||
储存温度:- 20~60℃ | |||
工作湿度:10~90% | |||
储存湿度:5~90% | |||
安规认证 | |||
安全机构/标志 | 医疗 | 通信 | |
CB | IEC60601-1 | IEC60950-1 | |
UL | ANSI/AAMI ES60601-1 | UL60950-1 | |
CAN/CSA C22.2 NO.60601-1 | CAN/CSA C22.2 NO.60950-1 | ||
TUV | EN60601-1 | EN60950-1 | |
RCM | - | AS/NZS 60950.1 | |
J60950-1(For Class II only) | |||
机械规格 | |||
102(长)*50(宽)*33.5(高)mm | |||
应用场所 | |||
适用于医疗、信息通讯设备类电源适配器 | |||
输出数据 | ||||||||
型号 | 电压 | 电流 | 纹波 | 电压公差 | 线性与负数调整率 |
| 平均效率 | 启动延迟时间 |
UES36-XXXYYYSPA | 9.0-10.0 | 0.01-4.00 | 400 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 10.1-11.0 | 0.01-3.56 | 400 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 11.1-12.0 | 0.01-3.24 | 400 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 12.1-13.0 | 0.01-2.97 | 400 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 13.1-14.0 | 0.01-2.74 | 400 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 14.1-15.0 | 0.01-2.55 | 400 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 15.1-16.0 | 0.01-2.38 | 400 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 16.1-17.0 | 0.01-2.23 | 180 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 17.1-18.0 | 0.01-2.10 | 180 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 18.1-19.0 | 0.01-1.98 | 180 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 19.1-20.0 | 0.01-1.88 | 180 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 20.1-21.0 | 0.01-1.79 | 180 | ±5% | 线性调整率:±1% | Y Y | 88.30% | ≤3s |
UES36-XXXYYYSPA | 21.1-22.0 | 0.01-1.70 | 180 | ±5% | 负载调整率:±5% | Y Y | 88.30% | ≤3s |
UES36-XXXYYYSPA | 22.1-23.0 | 0.01-1.62 | 180 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 23.1-24.0 | 0.01-1.55 | 180 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 24.1-25.0 | 0.01-1.49 | 180 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 25.1-26.0 | 0.01-1.37 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 26.1-27.0 | 0.01-1.32 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 27.1-28.0 | 0.01-1.28 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 28.1-29.0 | 0.01-1.23 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 29.1-30.0 | 0.01-1.19 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 30.1-31.0 | 0.01-1.15 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 31.1-32.0 | 0.01-1.12 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 32.1-33.0 | 0.01-1.08 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 33.1-34.0 | 0.01-1.05 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 34.1-35.0 | 0.01-1.02 | 240 | ±5% | Y Y | 88.30% | ≤3s | |
UES36-XXXYYYSPA | 35.1-36.0 | 0.01-1.43 | 240 | ±5% | Y Y | 88.30% | ≤3s |
