点击查看详细资料| 医疗和I.T.E.安全认证 |
| 2 MOPP 隔离保护 |
| 漏电流 ≤ 100μA |
| DOE 六级能效 |
| 待机功耗≤0.075W |
| 工作海拨高度5000米 |
| 输入电压 | 90-264VAC | ||||||||||
| 频率范围 | 47-63HZ | ||||||||||
| 输入电流 | 1.0A，在115VAC 输入条件下 | ||||||||||
| 接触电流 | ≤100μA在264VAC输入条件下 | ||||||||||
| 环境 | 一般 | ||||||||||
| 工作温度 | -10〜50℃ | 外形尺寸 | 76.2（长）x50.8（宽）x27.5（高）mm | ||||||||
| 储存温度 | -20〜70℃ | 重量 | 85g | ||||||||
| 工作湿度 | 10〜90％RH, 无冷凝 | 平均故障间隔时间 | > 100,000小时MIL-HDBK-217，在25℃环境温度下。 | ||||||||
| 工作海拔高度 | 5000m | ||||||||||
| 安规认证 | ||
| 安全机构/标志 | 医疗 | 通信 |
| CB | IEC60601-1 | IEC62368-1 |
| NRTL | ANSI/AAMI ES60601-1 CAN/CSA C22.2 NO.60601-1 | - |
| TUV-Mark | EN60601-1 | EN62368-1 |
型号 | 电压 | 电流 | 额定功率 | 纹波 | 电压公差 | 线性与负数调整率 | 平均效率 | 启动延迟时间 |
UES30-XXXYYYSPA -OP | 5.0 | 0.01-6.0 | 30W | 120 | ±5% | 线性调整率: ±1% 负载调整率: ±5% | 86.0% | ≤3s |
5.1-6.0 | 0.01-5.88 | 30W | 120 | ±5% | 86.0% | ≤3s | ||
6.1-7.5 | 0.01-4.92 | 30W | 120 | ±5% | 87.7% | ≤3s | ||
7.6-8.0 | 0.01-3.95 | 30W | 120 | ±5% | 87.7% | ≤3s | ||
8.1-9.0 | 0.01-3.70 | 30W | 120 | ±5% | 87.7% | ≤3s | ||
9.1-10.0 | 0.01-3.30 | 30W | 120 | ±5% | 87.7% | ≤3s | ||
10.1-11.0 | 0.01-2.97 | 30W | 120 | ±5% | 87.7% | ≤3s | ||
11.1-12.0 | 0.01-2.70 | 30W | 120 | ±5% | 87.7% | ≤3s | ||
12.1-13.0 | 0.01-2.48 | 30W | 120 | ±5% | 87.7% | ≤3s | ||
13.1-14.0 | 0.01-2.29 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
14.1-15.0 | 0.01-2.13 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
15.1-16.0 | 0.01-1.99 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
16.1-17.0 | 0.01-1.86 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
17.1-18.0 | 0.01-1.75 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
18.1-19.0 | 0.01-1.66 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
| 19.1-20.0 | 0.01-1.57 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
| 20.1-21.0 | 0.01-1.49 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
| 21.0-22.0 | 0.01-1.42 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
| 22.1-23.0 | 0.01-1.36 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
| 23.1-24.0 | 0.01-1.30 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
| 24.1-27.0 | 0.01-1.24 | 30W | 200 | ±5% | 87.7% | ≤3s | ||
| 27.1-30.0 | 0.01-1.11 | 30W | 300 | ±5% | 87.7% | ≤3s | ||
| 30.1-33.0 | 0.01-1.00 | 30W | 300 | ±5% | 87.7% | ≤3s | ||
| 33.1-36.0 | 0.01-0.91 | 30W | 300 | ±5% | 87.7% | ≤3s | ||
| 36.1-39.0 | 0.01-0.83 | 30W | 300 | ±5% | 87.7% | ≤3s | ||
| 39.1-42.0 | 0.01-0.77 | 30W | 300 | ±5% | 87.7% | ≤3s | ||
| 42.1-45.0 | 0.01-0.71 | 30W | 300 | ±5% | 87.7% | ≤3s | ||
| 45.1-48.0 | 0.01-0.67 | 30W | 300 | ±5% | 87.7% | ≤3s |
